GNF101 Fiber Optic Rotary Joint
Single fiber optic rotary joint with single-mode and multi-mode options. While the multi-mode fibers can carry signals on several different paths or modes through the fiber core, single-mode fibers carry signals on only one path or mode of transmission. The advantage of single-mode is low attenuation with a very high data capacity.
GNF1 rotary joint with 1 fiber channel, contactless transmission of the highest data rates, Bi-directional data.
- Optical signal only or hybrid unit(optical+electric) is transmitted
- Fiber optic transimt signal is secretly,no electromagnetic interference
Features
- 1 channel single-mode
- Insertion loss:＜2dB
- Low insertion loss, high speed
- high grade sealing
- Precision ball bearings for long life
Benefits
GNF101 Specfications
- Wavelength range
1310 / 1550nm
- Insertion loss
＜2dB
- Return loss (SM)
＞45 dB
- Max. Operating Speed
1000rmp
- Type
SM
- Estimated life cycle
150 million revolutions
- Optical power handling
23 dBm
- Working temperature
-30 to 80 C
- Housing material
Stainless steel
- Protect Level
IP65
- Pulling strength
10N
- Start up torque
＜0.01 Nm
- Work Humidity
10% to 85% RH
- --
--
- --
--
- --
--
