GNF4 Fiber Optic Rotary Joint
GNF4 rotary joint with 4 fiber channel, can upports practically every data format,for analog data transmission,passive rotary connection.
- GNF4 fiber optic rotary joint, 4 channel fiber(single mode),
- Optical signal only or hybrid unit(optical+electric) is transmitted
- Fiber optic transimt signal is secretly,no electromagnetic interference
Features
- 4 channel single-mode
- Low insertion loss, high speed
- high grade sealing
- Precision ball bearings for long life
Benefits
- Fiber optic transimt signal is secretly
- Small volume, light weight
- 360° continuous rotation
- IP65
GNF401 Specfications
- Wavelength range
1310 / 1550nm
- Insertion loss
＜3dB
- Return loss
＞45 dB
- Max. Operating Speed
200rmp
- Type
SM
- Estimated life cycle
150 million revolutions
- Optical power handling
23 dBm
- Crosstalk
>50 dB
- Working temperature
-30℃～+80℃
- Housing material
Stainless steel
- Protect Level
IP65
- Pulling strength
10N
- Start up torque
＜0.5 Nm
- Work Humidity
10% to 85% RH
- --
--
- --
--
