GNF8 Fiber Optic Rotary Joint
GNF8 rotary joint with 8 fiber channel, can upports practically every data format,for analog data transmission,passive rotary connection.
- GNF8 fiber optic rotary joint,8 channel fiber(single mode or multi-mode),
- Optical signal only or hybrid unit(optical+electric) is transmitted
- Fiber optic transimt signal is secretly,no electromagnetic interference
Features
- 8 channel single-mode
- Low insertion loss, high speed
- high grade sealing
- Precision ball bearings for long life
Benefits
- Low torque minimizes system torque budget
- Fiber optic transimt signal is secretly
- 360° continuous rotation
- IP65
GNF801 Specfications
- Wavelength range
1310 / 1550nm ± 20nm
- Insertion loss
＜3.5dB
- Return loss (SM)
＞50 dB
- Max. Operating Speed
200rmp
- Type
SM
- Estimated life cycle
150 million revolutions
- Optical power handling
23 dBm
- Working temperature
-30 to 80 C
- Housing material
Stainless steel
- Protect Level
IP65
- Pulling strength
10N
- Start up torque
＜1 Nm
- Work Humidity
10% to 85% RH
- --
--
- --
--
- --
--
